VLAN Commands
switchport general pvid
Cisco 220 Series Smart Plus Switches Command Line Interface Reference Guide Release 1.0.0.x
Syntax
switchport general pvid
no switchport general pvid
Parameters
vlan-id
• —The VLAN as the PVID.
Default Configuration
The default VLAN is the PVID.
Command Mode
Interface Configuration (Ethernet, port channel) mode
Examples
Example 1—The following example configures gi2 as a general port and sets its
PVID to 234:
switchxxxxxx(config)# interface gi2
switchxxxxxx(config-if)# switchport mode general
switchxxxxxx(config-if)# switchport general pvid 234
Example 2—The following example adds VLAN 2 as tagged, and VLAN 100 as
untagged to the general port gi 1 4, defines VID 100 as the PVID, and then reverts to
the default PVID (VID=1).
switchxxxxxx(config)# interface gi14
switchxxxxxx(config-if)# switchport mode general
switchxxxxxx(config-if)# switchport general allowed vlan add 2 tagged
switchxxxxxx(config-if)# switchport general allowed vlan add 100 untagged
switchxxxxxx(config-if)# switchport general pvid 100
switchxxxxxx(config-if)# no switchport general pvid
Example 3—The following example configures VLAN on gi 1 4 as untagged on input
and untagged on output:
switchxxxxxx(config)# interface gi14
switchxxxxxx(config-if)# switchport mode general
switchxxxxxx(config-if)# switchport general pvid 2
