Removing the CrossTrax Traction Manifold Assembly (continued)
Installing the CrossTrax Traction Manifold Assembly
Hydraulic System: Service and Repairs
3. Raise and support the operator seat. Locate the traction manifold assembly.
4. Clean the hydraulic hose ends and fittings on the traction manifold assembly
to prevent contaminants from entering into the hydraulic system.
5. For assembly purposes, label all the hydraulic hoses that are connected to
the traction manifold fittings and ports.
6. Disconnect the hydraulic hoses that are connected to the hydraulic fittings
and ports on the traction manifold assembly
Note: The hoses at the traction manifold assembly ports LR and RR should
be disconnected at the hydraulic tubes before removal from the traction
manifold assembly shown in
7. Install clean caps or plugs in the hose and fitting openings to prevent system
contamination.
8. Support the traction manifold assembly to prevent it from falling.
9. Remove the 2 bolts (item 12 in
133) that secure the traction manifold assembly to the mount plate, and
remove the traction manifold assembly from the machine.
10. If the mounts (item 8 in
of the washer (item 9 in
replace damaged mounts and ensure that the washer is installed between
new mounts and top of the mount plate.
11. If the hydraulic fittings are to be removed from the traction manifold assembly,
mark the fitting orientation for assembly purposes. Remove the fittings from
the traction manifold assembly and discard the O-rings from the fittings.
An orifice is threaded into the traction manifold assembly ports
OR1, OR2, OR3, and OR4. If any orifice is removed from the traction
manifold assembly, ensure to label its position for assembly
purposes.
If any orifice was removed from the traction manifold assembly,
ensure to secure the orifice into correct port before installing the
fittings.
Figure 134.
Figure 133) and 4 washers (item 7 in
Figure 133) are worn or damaged, note the location
Figure 133) for assembly purposes. Remove and
IMPORTANT
IMPORTANT
Page 4–130
(Figure 134).
