Toro Groundsmaster 360 Service Manual page 41

Removing the Air Cleaner System
Installing the Air Cleaner System
Groundsmaster 360
16225SL Rev C
Note: Refer to the Operator's Manual for maintenance procedures and intervals
of the air cleaner.
1. Park the machine on a level surface, lower the cutting deck, shut off the
engine, set the parking brake, and remove the key from the key switch.
2. Unlatch the hood and raise it.
3. Remove the air cleaner components as shown in
4. Examine the air cleaner housing and cover (items 11 and 9 in
wear or damage that could cause possible air leaks.
5. Examine the air hoses for wear or damage and replace the hoses if
necessary.
6. Examine the hood seals for wear or damage and replace the seals if
necessary.
Leaks in the air filter system will allow dirt to enter into the engine
and can cause serious engine damage. Ensure that all the air cleaner
components are in good condition and are properly secured during
installation.
1. Assemble the air cleaner system as shown in
A. Ensure that the vacuator valve (item 8 in
installation.
B. If the service indicator (item 13 in
from the housing, apply sealant to the threads of the nipple, torque the
nipple to 3.4 N·m (30 in-lb), and install the service indicator onto the
nipple.
2. Lower the hood and secure it with the latches.
IMPORTANT
Figure
Page 3–9
Figure 8.
Figure
Figure 8.
Figure 8) is pointed down after
8) or pipe nipple were removed
Diesel Engine: Service and Repairs
8) for
