5. In the Flow Navigator, click the Generate Bitstream option which runs synthesis,
implementation, and generates a BIT file
No Implementation Results are available is displayed. The BIT file can be
found under the following directory:
kcu105_axis_dataplane/hardware/vivado/runs_base/trd03_base.runs/
impl_1
AXIS represents AXI Streaming.
Note:
X-Ref Target - Figure 4-2
PCIe Streaming Data Plane TRD
UG920 (v2017.1) June 01, 2017
Figure 4-2: Base Design – Generate Bitstream
www.xilinx.com
Chapter 4: Implementing and Simulating the Design
(Figure 4-2). Click Yes if a window indicating
UG920_c4_02_041117
