About SCSI LUN Discovery
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m

Starting SCSI LUN Discovery

To begin SCSI LUN discovery using Device Manager, follow these steps:
Choose FC > Advanced > LUNs.
Step 1
You see the LUN Configuration dialog box.
Figure 35-1
Set StartDiscovery to local, remote or both.
Step 2
Choose the DiscoveryType and OS.
Step 3
Click Apply to begin discovery.
Step 4

About Initiating Customized Discovery

Customized discovery consists of a list of VSAN and domain pairs that are selectively configured to
initiate a discovery. The domain ID is a number from 0 to 255 in decimal or a number from 0x0 to 0xFF
in hex.

Initiating Customized Discovery

To initiate a customized discovery using Device Manager, follow these steps:
Step 1 Click the VSAN drop-down menu and select the VSAN in which you want to initiate a customized
discovery.
Step 2 Click FC > Advanced > LUNs.
You see the LUN Configuration dialog box.
Set StartDiscovery to local, remote or both.
Step 3
Fill in the DiscoveryType and OS fields.
Step 4
Cisco MDS 9000 Family Fabric Manager Configuration Guide
35-2
LUN Configuration Dialog Box
Chapter 35 Discovering SCSI Targets
OL-17256-03, Cisco MDS NX-OS Release 4.x
