iSCSI Authentication Setup Guidelines and Scenarios
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Set the Zone Name field to iscsi-zone-2 and click OK.
d.
Select the iscsi-zone-2 folder in the left navigation pane and click Insert.
e.
Set the ZoneBy radio button toWWN.
f.
Set the Port WWN to the pWWN for one of the Fibre Channel targets (for example,
g.
21:00:00:20:37:6f:fe:5). and click Add.
Set the Port WWN to the pWWN for another of the Fibre Channel targets (for example,
h.
21:00:00:20:37:a6:a6:5d). and click Add.
Set the ZoneBy radio button to iSCSI IP Address/Subnet.
i.
Set the IP Address/Mask field to the IP Address for Host 2 iSCSI initiator (10.15.1.11) and click
j.
Add.
Step 13 Create a zone set in VSAN 2 and activate it.
In Fabric Manager, choose Zones > Edit Local Full Zone Database.
a.
Select VSAN 2 from the VSAN drop-down menu in the Edit Local Full Zone Database dialog box.
b.
Select the Zoneset folder in the left navigation pane and click Insert.
c.
Set the Zoneset Name to zonset-iscsi-2 and click OK.
d.
Click on the zoneset-iscsi-2 folder and click Insert.
e.
Set the Zone Name field to iscsi-zone-2 and click OK.
f.
Click Activate to activate the new zone set.
g.
Click Continue Activation to finish the activation.
h.
Start the iSCSI clients on both hosts
Step 14
Show all the iSCSI sessions.
Step 15
a. In Device Manager, choose Interface > Monitor > Ethernet and select the iSCSI connections tab
to show all the iSCSI sessions.
In Device Manager, choose IP > iSCSI and select the Session Initiators tab.
b.
c. Click Details.
Step 16 In Fabric Manager, choose End Devices > iSCSI in the Physical Attributes pane to verify the details of
the two iSCSI initiators.
Step 17 In Fabric Manager, choose Zones > Edit Local Full Zone Database to view the active zone set. The
iSCSI initiators' FC IDs are resolved.
In Device Manager, choose FC > Name Server. The Fibre Channel name server shows the virtual N
Step 18
ports created for the iSCSI hosts.
In Device Manager, Choose FC > Name Server.
Step 19
Click the Advanced tab. Verify the detailed output of the iSCSI initiator nodes in the Fibre Channel
Step 20
name server.
