IVR Zones and IVR Zone Sets
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m

Configuring IVR Zones and IVR Zone Sets

To create IVR zones and IVR zone sets, follow these steps:
Command
Step 1
switch# config t
switch(config)#
Step 2
switch(config)# ivr zone name sample_vsan2-3
switch(config-ivr-zone)#
Step 3
switch(config-ivr-zone)# member pwwn 21:00:00:e0:8b:02:ca:4a
vsan 3
Step 4
switch(config-ivr-zone)# member pwwn 21:00:00:20:37:c8:5c:6b
vsan 2
Step 5
switch(config-ivr-zone)# exit
switch(config)#
Step 6
switch(config)# ivr zone name sample_vsan4-5
switch(config-ivr-zone)#
Step 7
switch(config-ivr-zone)# member pwwn 21:00:00:e0:8b:06:d9:1d
vsan 4
Step 8
switch(config-ivr-zone)# member pwwn 21:01:00:e0:8b:2e:80:93
vsan 4
Step 9
switch(config-ivr-zone)# member pwwn 10:00:00:00:c9:2d:5a:dd
vsan 5
Step 10
switch(config-ivr-zone)# exit
switch(config)#
Step 11
switch(config)# ivr zoneset name Ivr_zoneset1
switch(config-ivr-zoneset)#
Step 12
switch(config-ivr-zoneset)# member sample_vsan2-3
Step 13
switch(config-ivr-zoneset)# member sample_vsan4-5
Step 14
switch(config-ivr-zoneset)# exit
switch(config)
Cisco MDS 9000 Family CLI Configuration Guide
23-30
Chapter 23 Configuring Inter-VSAN Routing
Purpose
Enters configuration mode.
Creates an IVR zone named
sample_vsan2-3.
Adds the specified pWWN in
VSAN 3 as an IVR zone
member.
Adds the specified pWWN in
VSAN 2 as an IVR zone
member.
Reverts to configuration mode.
Creates an IVR zone named
sample_vsan4-5.
Adds the specified pWWN in
VSAN 4 as an IVR zone
member.
Adds the specified pWWN in
VSAN 4 as an IVR zone
member.
Adds the specified pWWN in
VSAN 5 as an IVR zone
member.
Reverts to configuration mode.
Creates an IVR zone set named
Ivr_zoneset1.
Adds the sample_vsan2-3 IVR
zone as an IVR zone set
member.
Adds the sample_vsan4-5 IVR
zone as an IVR zone set
member.
Returns to configuration mode.
OL-18084-01, Cisco MDS NX-OS Release 4.x
