Displaying Protocol Security Information - Cisco AP776A - Nexus Converged Network Switch 5020 Configuration Manual

DHCHAP
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
To configure the AAA authentication, follow these steps:
Command
Step 1
switch# config t
Step 2
switch(config)# aaa authentication dhchap
default group TacacsServer1
switch(config)# aaa authentication dhchap
default local
switch(config)# aaa authentication dhchap
default group RadiusServer1

Displaying Protocol Security Information

Use the show fcsp commands to display configurations for the local database (see
38-6).
Example 38-1 Displays DHCHAP Configurations in FC Interfaces
switch# show fcsp interface fc1/9
fc1/9:
Example 38-2 Displays DHCHAP Statistics for an FC Interface
switch# show fcsp interface fc1/9 statistics
fc1/9:
Example 38-3 Displays the FC-SP WWN of the Device Connected through a Specified Interface
switch# show fcsp interface fc 2/1 wwn
fc2/1:
Example 38-4 Displays Hash Algorithm and DHCHAP Groups Configured for the Local Switch
switch# show fcsp dhchap
Supported Hash algorithms (in order of preference):
DHCHAP_HASH_MD5
DHCHAP_HASH_SHA_1
Supported Diffie Hellman group ids (in order of preference):
Cisco MDS 9000 Family CLI Configuration Guide
38-10
fcsp authentication mode:SEC_MODE_ON
Status: Successfully authenticated
fcsp authentication mode:SEC_MODE_ON
Status: Successfully authenticated
Statistics:
FC-SP Authentication Succeeded:5
FC-SP Authentication Failed:0
FC-SP Authentication Bypassed:0
fcsp authentication mode:SEC_MODE_ON
Status: Successfully authenticated
Other device's WWN:20:00:00:e0:8b:0a:5d:e7
Chapter 38
Purpose
Enters configuration mode.
Enables DHCHAP to use the TACACS+ server group
(in this example, TacacsServer1) for authentication.
Enables DHCHAP for local authentication.
Enables DHCHAP to use the RADIUS server group
(in this example, RadiusServer1) for authentication.
OL-18084-01, Cisco MDS NX-OS Release 4.x
Configuring FC-SP and DHCHAP
Example 38-1 through
