MITSUBISHI CNC
Appendix 1 Explanation of Parameters
【#1086】 G0lntp G00 non-interpolation
Select the G00 travel path type.
0: Move linearly toward the end point. (interpolation type)
1: Move to the end point of each axis at the rapid traverse feedrate for each axis. (non-
(Note) If this parameter is set to "1", neither of the following functions will be available: rapid traverse
【#1087】 G96_G0 Constant surface speed control by rapid traverse feed command
Select how to handle the surface speed for the G00 command when using the constant surface
speed control function.
0: Calculate the surface speed constantly even during G00 movement
1: Calculate the surface speed at the block end point in the G00 command
【#1088】 G30SL Disable G30 soft limit
Select how to handle the soft limit during G30 (2nd reference position return).
0: Enable
1: Disable
【#1091】 Mpoint Ignore middle point
Select how to handle the middle point during G28 and G30 reference position return.
0: Pass the middle point designated in the program and move to the reference position.
1: Ignore the middle point designated in the program and move straight to the reference position.
【#1092】 Tchg _A Replace tools for additional axis
Select the movement of the additional axis at the tool change position return command.
0: The additional axis will not move
1: After the standard axis returns, the additional axis will also return to the tool change position
【#1093】 Wmvfin Synchronization between part systems method
Select the timing of synchronization between part systems when using the multi-part system.
When the travel command is found in the synchronization command (!, M) block:
0: Synchronize before executing travel command
1: Synchronize after executing travel command
【#1094】 Tl_SBK Select life count for single block (for L system only)
Select whether to count the data units to be used for single block operation when using the tool life
management II function (L system).
0: Not count
1: Count
【#1095】 T0tfof TF output
Select how to handle TF for T00 command.
0: TF will be output
1: TF wont be output
【#1096(PR)】 T_Ltyp Tool life management type
Select the tool life management type.
1: Life management l
2: Life management ll
3: Life management lll (for M system only)
228
interpolation)
constant inclination acceleration/deceleration and rapid traverse constant inclination multi-step
acceleration/deceleration.
In this type, how long and how many times the program commanded tool is used are
accumulated to monitor the usage state.
This method is the same as tool life management I, but with the spare tool selection function.
A spare tool is selected from a group of tool commands commanded in the program.
Tool compensation (tool length compensation and tool radius compensation) is carried out for
the selected tool.
The usage time, frequency of use or the wear amount of the tool which is designated by the
program is accumulated, and the tool usage state is monitored.
It is not managed by the group number.
(Note) When "3" is set for the L system, the Life management l is selected.
