-i <ip address>
-w <ip address>
-n <netmask>
-g <gateway>
-V
E E x x a a m m p p l l e e
>internet -M 1 -S tcom -u username -p password -a 0 -t -1 -i 0.0.0.0
WAN1 Internet Mode set to PPPoE/PPPoA
WAN1 ISP Name set to tcom
WAN1 Username set to username
WAN1 Password set successful
WAN1 PPP Authentication Type set to PAP/CHAP
WAN1 Idle timeout set to always-on
WAN1 Gateway IP set to 0.0.0.0
> internet -V
WAN1 Internet Mode:PPPoE
ISP Name: tcom
Username: username
Authentication: PAP/CHAP
Idle Timeout: -1
WAN IP: Dynamic IP
T e l n e t C o m m a n d
T e l n e t C o m m a n d
This command allows users to enable or disable the IP routing subnet for your router.
ip 2ndsubnet <Enable/Disable>
It means that PPPoE server will assign an IP address
specified here for CPE (PPPoE client).
If you type 0.0.0.0 as the <ip address>, ISP will assign
suitable IP address for you. However, if you type an IP
address here, the router will use that one as a fixed IP.
It means to assign WAN IP address for such connection.
Please type an IP address here for WAN port.
It means to assign netmask for WAN connection. You
have to type 255.255.255.xxx (x is changeable) as the
netmask for WAN port.
It means to assign gateway IP for such WAN
connection.
It means to view Internet Access profile.
: i p 2 n d s u b n e t
: i p 2 n d s u b n e t
