-i <bandwidth>
-o <bandwidth>
-r <index:ratio>
-u <mode>
-p <ratio>
-t <mode>
-V
-D
[...]
E x a m p
E x a m p
> qos setup -m 3 -i 9500 -o 8500 -r 3:20 -u 1 -p 50 -t 1
WAN1 QOS mode is both
Wan 1 is XDSL model ,don,t need to set up
Wan 1 is XDSL model ,don,t need to set up
WAN1 class 3 ratio set to 20
Vigor2860 Series User's Guide
l e
l e
0: disable.
1: in, apply to incoming traffic only.
2: out, apply to outgoing traffic only.
3: both, apply to both incoming and outgoing traffic.
Default is enable (for outgoing traffic).
It means to set inbound bandwidth in kbps (Ethernet
WAN only)
The available setting is from 1 to 100000.
It means to set outbound bandwidth in kbps (Ethernet
WAN only). The available setting is from 1 to 100000.
It means to set ratio for class index, in %.
It means to enable bandwidth control for UDP.
0: disable
1: enable
Default is disable.
It means to enable bandwidth limit ratio for UDP.
It means to enable/disable Outbound TCP ACK
Prioritize.
0: disable
1: enable
Show all the settings.
Set all to factory default (for all WANs).
It means that you can type in several commands in
one line.
