3 . 1 . 3 I n t e r n e t A c
3 . 1 . 3 I n t e r n e t A c
For the router supports multi-WAN function, the users can set different WAN settings (for
WAN1/WAN2/WAN3/WAN4) for Internet Access. Due to different Physical Mode for WAN
interface, the Access Mode for these connections also varies. Refer to the following figures.
Available settings are explained as follows:
Item
Index
Display Name
Physical Mode
c e s s
c e s s
Description
Display the WAN interface.
It shows the name of the WAN1/WAN2/WAN3/WAN4
that entered in general setup.
It shows the physical connection for
WAN1(ADSL/VDSL2) /WAN2 (Ethernet) /WAN3/WAN4
85
Vigor2860 Series User's Guide
