CHK
-s CHK [START_P]
[END_P]
-d CHK [START_P]
[END_P]
Vigor2860 Series User's Guide
profile.
PROTOCOL =0, means any
PROTOCOL =1, means ICMP
PROTOCOL =2, means IGMP
PROTOCOL =6, means TCP
PROTOCOL =17, means UDP
PROTOCOL =255, means TCP/UDP
Other values mean other protocols.
Example:
object service obj 8 -i 0
It means the check action for the port setting.
0=equal(=), when the starting port and ending port
values are the same, it indicates one port; when the
starting port and ending port values are different, it
indicates a range for the port and available for this
service type.
1=not equal(!=), when the starting port and ending port
values are the same, it indicates all the ports except
the port defined here; when the starting port and ending
port values are different, it indicates that all the ports
except the range defined here are available for this
service type.
2=larger(>), the port number greater than this value is
available..
3=less(<), the port number less than this value is
available for this profile.
It means to set souce port check and configure port
range (1~65565) for TCP/UDP.
END_P, type a port number to indicate source port.
Example:
object service obj 3 -s 0 100 200
It means to set destination port check and configure port
range (1~65565) for TCP/UDP.
END_P, type a port number to indicate destination port.
