Security
[SSID_NUMBER]
[mode][key][index]
ratectl [ssid_num
enable upload
download]
isolate [ssid_num lan
member]
It means to configure security settings for the wirelesss
connection.
SSID_NUMBER: Type 1, 2, 3 or 4 to specify SSID1,
SSID2, SSID3 or SSID4.
mode: Available settings are:
disable:
wpa1x:
wpa21x:
wpamix1x: Mixed (WPA+WPA2/802.1x only)
wep1x:
wpapsk:
wpa2psk:
wpamixpsk:
wep:
key, index: Moreover, you have to add keys for wpapsk,
wpa2psk, wpamixpsk and wep, and specify index
number of schedule profiles to be followed by the
wireless connection.
WEP keys must be in 5/13 ASCII text string or 10/26
Hexadecimal digit format; WPA keys must be in 8~63
ASCII text string or 64 Hexadecimal digit format.
It means to set the rate control for the specified SSID.
ssid_num: Choose 1, 2, 3 or 4 to specify SSID1, SSID2,
SSID3 or SSID4.
enable: It means to enable the function of the rate
control for the specified SSID. 0: disable and 1:enable.
upload: It means to configure the rate control for data
upload. The unit is kbps.
download: It means to configure the rate control for data
download. The unit is kbps.
It means to isolate the wireless connection for LAN
and/or Member.
759
No security.
WPA/802.1x Only
WPA2/802.1x Only
WEP/802.1x Only
WPA/PSK
WPA2/PSK
Mixed (WPA+WPA2)/PSK
WEP
