PPPoE/PPPoA Client
MPoA (RFC1483/2684)
After finished the above settings, click OK to save the settings and return to previous page.
A
A
d
d
v
v
a
a
n
n
Such configuration is applied to upstream packets. Such information will be provided by ISP.
Please contact with your ISP for detailed information.
Vigor2860 Series User's Guide
c
c
e
e
d
d
to execute for WAN detection.
Ping IP – If you choose Ping Detect as detection mode, you
have to type IP address in this field for pinging.
TTL (Time to Live) – Displays value for your reference.
TTL value is set by telnet command.
Enter your allocated username, password and authentication
parameters according to the information provided by your
ISP.
ISP Name – Type in the name of your ISP.
Username – Type in the username provided by ISP in this
field. The maximum length of the name you can set is 80
characters.
Password – Type in the password provided by ISP in this
field. The maximum length of the password you can set is
48 characters.
PPP Authentication – Select PAP only or PAP or CHAP
for PPP.
Always On – Check it to keep the network connection
always.
Idle Timeout – Set the timeout for breaking down the
Internet after passing through the time without any action.
Fixed IP – Click Yes to use this function and type in a
fixed IP address in the box of Fixed IP Address.
Obtain an IP address automatically – Click this button to
obtain the IP address automatically.
Router Name – Type in the router name provided by
ISP.
Domain Name – Type in the domain name that you
have assigned.
Specify an IP address – Click this radio button to specify
some data.
IP Address – Type in the private IP address.
Subnet Mask – Type in the subnet mask.
Gateway IP Address – Type in gateway IP address.
DNS Server IP Address - Type in the primary IP address
for the router if you want to use Static IP mode. If
necessary, type in secondary IP address for necessity in the
future.
