Limited_bandwidth Ratio
Note: The rate of outbound/inbound must be smaller than the real bandwidth to ensure
correct calculation of QoS. It is suggested to set the bandwidth value for inbound/outbound
as 80% - 85% of physical network speed provided by ISP to maximize the QoS
performance.
E d i t t h
E d i t t h
1. The first three (Class 1 to Class 3) class rules can be adjusted for your necessity. To add,
edit or delete the class rule, please click the Edit link of that one.
2. After you click the Edit link, you will see the following page. Now you can define the
name for that Class. In this case, "Test" is used as the name of Class Index #1.
Vigor2860 Series User's Guide
e C l a s s R u l e f o r Q
e C l a s s R u l e f o r Q
check this box to push ACK of upload faster to speed the
network traffic.
The ratio typed here is reserved for limited bandwidth of
UDP application.
o S
o S
