1 . 2 L E D I n d i c
1 . 2 L E D I n d i c
Before you use the Vigor router, please get acquainted with the LED indicators and connectors
first.
1 . 2 . 1 F o r V i g o
1 . 2 . 1 F o r V i g o
LED
ACT (Activity)
WAN2
QoS
USB1~2
DSL
WCF
VPN
DoS
LED on Connector
WAN2
(Giga)
GigaLAN
1~6
a t o r s a n d C o n
a t o r s a n d C o n
r 2 8 6 0
r 2 8 6 0
Status
Blinking
Off
On
Off
Blinking
On
On
Blinking
On
Blinking
On
On
Off
Blinking
On
Blinking
Left On
LED
Off
Blinking
Right On
LED
Off
Left On
LED
Off
Blinking
Right On
LED
Off
n e c t o r s
n e c t o r s
Explanation
The router is powered on and running normally.
The router is powered off.
Internet connection is ready.
Internet connection is not ready.
The data is transmitting.
The QoS function is active.
USB device is connected and ready for use.
The data is transmitting.
The router is ready to access Internet through DSL link.
Slowly: The DSL connection is ready.
Quickly: The connection is training.
The Web Content Filter is active. (It is enabled from
Firewall >> General Setup).
The VPN tunnel is active.
VPN services are disabled
Traffic is passing through VPN tunnel.
The DoS function is active.
It will blink while detecting an attack.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps
3
Vigor2860 Series User's Guide
