dir
idle=[value]
palive
For Dial-Out Settings
ctype
dialto
ltype
oname
Vigor2860 Series User's Guide
It means the call direction. Available settings are b, o
and i.
b – Both
o – Dial-Out
i – Dial-In.
It means Always on and Idle Time out.
Available values include:
-1 – it means always on for dial-out.
0 – it means always on for dial-in.
Other numbers (e.g., idle=200, idle=300, idle=500)
mean the router will be idle after the interval (seconds)
configured here.
It means to enable PING to keep alive.
-1 – disable the function.
1,2,3,4 – Enable the function and PING IP 1.2.3.4 to
keep alive.
It means "Type of Server I am calling".
"ctype=t" means PPTP.
"ctype=s" means IPSec.
"ctype= l" means L2TP(IPSec Policy None).
"ctype= l1" means L2TP(IPSec Policy Nice to Have).
"ctype= l2" means L2TP(IPSec Policy Must).
It means Server IP/Host Name for VPN. (such
as draytek.com or 123.45.67.89).
It means Link Type.
"ltype=0" means "Disable".
"ltype=1" means "64kbps".
"ltype=2" means "128kbps".
"ltype=3" means "BOD".
It means Dial-Out Username.
