For Vigor2860n-plus and Vigor2860ac series, the web page will be shown as follows:
Note: Settings in this page only applied to LAN port but not WAN port.
Available settings are explained as follows:
Item
Enable
LAN
Wireless LAN (2.4GHz)
Wireless LAN (5GHz)
Subnet
Description
Click it to enable VLAN configuration.
P1 – P6 – Check the LAN port(s) to group them under the
selected VLAN.
SSID1 – SSID4 – Check the SSID boxes to group them
under the selected VLAN.
SSID1 – SSID4 – Check the SSID boxes to group them
under the selected VLAN.
Choose one of them to make the selected VLAN mapping
to the specified subnet only. For example, LAN1 is
specified for VLAN0. It means that PCs grouped under
VLAN0 can get the IP address(es) that specified by the
subnet.
