ABB i-bus KNX Product Manual page 164

®
ABB i-bus KNX
Commissioning
There are three parameters below which can be used to enable group objects for each emergency lighting
converter; the group objects are used to start an emergency lighting test, to obtain the test result, or to
transmit converter status. These group objects relate to one converter only. The addressed emergency
lighting group objects for the output (e.g. numbers 40 to 42 for output A) receive equivalent information.
But there is only one addressed group object for all the converters. The information indicating which
converter the group object concerns is stored in the first byte of the object – the address byte.
Enable Group objects
"Trigger em lighting test"
Options:
Linked group object:
•
No: No group object is enabled for the emergency lighting converters to start an emergency lighting
test. Regardless of this, a test can be started for the converters via the addressed group object.
•
Yes, KNX DTP_CTC format: This enables a group object for the individual emergency lighting
converters which triggers and stops an emergency lighting test. The coding of the group object
corresponds to the KNX DPT specification for interworking between KNX devices.
•
Yes, DGN/S1.16.1 format: This enables a group object for the individual emergency lighting
converters which triggers and stops an emergency lighting test. The coding for the group object
corresponds to the predecessor device DGN/S 1.16.1. This means that an existing KNX emergency
lighting controller that has already operated with the DGN/S 1.16.1 can still be used, without the need
for new decoding.
•
Yes, DGN/S1.16.1 format with status: This enables a group object for the individual emergency
lighting converters which triggers and stops an emergency lighting test. This object not only controls
the test but can also provide its status. The coding for the group object corresponds to the
predecessor device DGN/S 1.16.1. This means that an existing KNX emergency lighting controller that
has already operated with the DGN/S 1.16.1 can still be used, without the need for new decoding.
162 2CDC507164D0201 | DG/S x.64.1.1
Selection of Duration and partial duration test:
Dependent parameters:
Duration test every
n tests
Options: 2...12...100
With alternating duration and partial duration tests, this parameter defines how often
the test is a duration test.
No
Yes, KNX format DPT_CTC
Yes, DGN/S1.16.1 format
Yes, DGN/S1.16.1 format with status
Trigger em lighting test (CTC)
Trigger em lighting test (DGN/S)
Trigger em lighting test/Status (DGN/S)
