61191 [Channel %1: ] Block %2: Multi-axis transformation not set up. Error code: %4
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: See error code for error cause. The alarm is triggerd by the following cycles: CYCLE800, 832.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy: Error code:
Number or parameter name of multi-axis transformation
Program Clear alarm with the RESET key. Restart part program
Continuation:
61192 [Channel %1: ] Block %2: Additional multi-axis transformations not set up. Error code:
%4
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: See error code for error cause. The alarm is triggerd by the following cycles: CYCLE800, 832.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy: Error code:
Number or parameter name of multi-axis transformation
Program Clear alarm with the RESET key. Restart part program
Continuation:
61193 [Channel %1: ] Block %2: compressor option not set up
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: The alarm is triggerd by the following cycles: CYCLE832.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy: --
Program Clear alarm with the RESET key. Restart part program
Continuation:
61194 [Channel %1: ] Block %2: spline interpolation option not set up
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: The alarm is triggerd by the following cycles: CYCLE832.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy: --
