Remedy:
Please inform the authorized personel/service department. The sum of the two option data
$ON_NUM_AXES_IN_SYSTEM and $ON_NUM_ADD_AXES_IN_SYSTEM must not exceed the maximum number
of axes (dependent on configuration).
Program
Switch control OFF - ON.
Continuation:
4009
Machine data %1 contains an illegal value.
Parameters:
%1 = String: MD identifier
Definitions:
A value has been entered which exceeds the value range or a limit value for a variable, a machine data or a function.
Reaction:
NC not ready.
Channel not ready.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy:
Enter correct values.
Program
Switch control OFF - ON.
Continuation:
4010
Invalid identifier used in machine data %1[%2]
Parameters:
%1 = String: MD identifier
%2 = Index: MD array index
Definitions:
When determining a name in the NCK tables (arrays) for: machine axes, Euler angles, direction vectors, normal vec-
tors, interpolation parameters and intermediate point coordinates, one of the following syntax rules for the identifier to
be entered has been violated:
- The identifier must be an NC address letter (A, B, C, I, J, K, Q, U, V, W, X, Y, Z), possibly with a numerical extension
(840D: 1-99)
- The identifier must begin with any 2 capital letters but not with $ (reserved for system variables).
- The identifier must not be a keyword of the NC language (e.g. POSA).
Reaction:
NC not ready.
Mode group not ready, also effective for single axes.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy:
Please inform the authorized personnel/service department. Enter the identifier for user-defined names with correct
syntax in the displayed MD.
- Machine axes: MD10000 $MN_AXCONF_MACHAX_NAME_TAB
- Euler angles: MD10620 $MN_EULER_ANGLE_NAME_TAB
- Normal vectors: MD10630 $MN_NORMAL_VECTOR_NAME_TAB
- Direction vectors: MD10640 $MN_DIR_VECTOR_NAME_TAB
- Interpolation parameters: MD10650 $MN_IPO_PARAM_NAME_TAB
- Intermediate point coordinates: MD10660 $MN_INTERMEDIATE_POINT_NAME_TAB
Program
Switch control OFF - ON.
Continuation:
Alarms
Diagnostics Manual, 07/2010, 6FC5398-8BP40-0BA0
NCK alarms
21
