MAINTENANCE
After adiustment. retiahten the axle nut to the specified
I
"
torque.
arm when tightening the axle nut helps ensure that the
adjusters on both sides are seated against their stops
and that the axle is in proper alignment. Always check to
be sure both sides are adjusted to the same marks on the
Re-check the chain play.
Tighten the adjusters and lock nuts.
I
Adjust the rear brake pedal play. (This step can be omitted in
the case of disc brakes).
wear indicator label so that the driven sprocket outer circle
is at the start of the green zone (the other side of the red
zone).
Adjust the rear brake light switch actuation point (on cable
operated rear drum brake models).
If, after adjustment, the adjuster's alignment mark is within
the red zone of the chain wear indicator label, replace the drive
NOTE
.
Always replace both sprockets when replacing the drive
chain for optimum wear characteristics.
After replacing and adjusting the drive chain, attach a wear in-
dicator label so that the alignment mark is at the start of the
green zone.
s . , ,
NOTE
Always replace both sprockets when replacing the drive
chain for ootimum wear characteristics.
END OF SWING ARM
On models without drive chain wear indicators measure the
length between the chain's pins (see next page).
ADJUSTMENT OF PRO-ARM TYPE
Loosen the bearing holder flange bolt.
Rotate the bearing holder using the pin-spanner in the
vehicle's tool set to adjust the drive chain play.
After adjustment, retighten the bearing holder flange bolt t o
the specified torque.
If, after adjustment, the driven sprocket outer circle is within
the red zone of the chain wear indicator label, replace the
drive chain (only for behicles with an indicator label affixed.)
On models without drive chain wear indicators measure the
length between the chain's pins (see next page)
chain and both sprockets (Only for vehicles with an indicator
RED ZONE
label affixed).
BEARING HOLDER FLANGE BOLT
PIN-SPANNER
1
RED ZONE
I
After replacing and adjustment of the drive chain, attach a
I
I
I
I
OUTER CIRCLE
2-22
Date of Issue : March, 1995
O
HONDA MOTOR CO.,LTD.
