IPv4 Static Routes

S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Disable the mgmt 0 interface.
Step 1
Configure this switch using the console connection.
Note
switch_3# config t
switch_3(config)# interface mgmt 0
switch_3(config-if)# no shutdown
switch_3(config-if)# exit
switch_3(config)#
switch_3# config t
switch_3(config)# interface vsan 1
switch_3(config-if)#
Configure the IP address and subnet mask.
Step 2
switch_3(config-if)# ip address 10.1.1.3 255.0.0.0
Enable the VSAN interface and exit interface configuration submode.
Step 3
switch_3(config-if)# no shutdown
switch_3(config-if)# exit
switch_3(config)#
Step 4 Enable IPv4 routing.
switch_3(config)# ip routing
switch_3(config)# exit
switch_3#
Display the routes.
Step 5
switch_3# show ip route
Codes: C - connected, S - static
C 10.0.0.0./8 is directly connected, vsan1
Verify the connectivity to Switch_1.
Step 6
switch_3# ping 10.1.1.1
PING 10.1.1.1 (10.1.1.1) 56(84) bytes of data.
64 bytes from 10.1.1.1: icmp_seq=1 ttl=64 time=1.19 ms
64 bytes from 10.1.1.1: icmp_seq=2 ttl=64 time=0.510 ms
64 bytes from 10.1.1.1: icmp_seq=3 ttl=64 time=0.653 ms
--- 10.1.1.1 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 2008 ms
rtt min/avg/max/mdev = 0.510/0.787/1.199/0.297 ms
IPv4 Static Routes
If your network configuration does not need an external router, you can configure IPv4 static routing on
your MDS switch.
