Installing System Images
•
The 5.0 system image does not work with the old bootloader.
Caution
If you upgrade the bootloader, make sure you have the correct file. NM-CIDS does not check to verify
Caution
that you have the correct file. If you upgrade with the wrong file, when you reboot, NM-CIDS will be
inaccessible and you will have to RMA it.

Installing the NM-CIDS System Image

The NM-CIDS bootloader must be at 1.0.17-1 before installing the 5.0 system image file. For the
Caution
procedure if needed, see
The bootloader has a timeout of 10 minutes, which means reimages over slow WAN links will fail. To
Note
avoid this situation, download the bootloader file to a local TFTP server and have the NM-CIDS reimage
from the local TFTP server.
To reimage NM-CIDS, follow these steps:
Download the NM-CIDS system image file (IPS-NM-CIDS-K9-sys-1.1-a-5.0-1.pkg) to the TFTP root
Step 1
directory of a TFTP server that is accessible from your NM-CIDS. For the procedure for locating
software on Cisco.com, see
Note
Log in to the router.
Step 2
Step 3 Enter enable mode:
router# enable
router(enable)#
Session to NM-CIDS:
Step 4
router(enable)# service-module IDS-Sensor slot_number/0 session
Cisco Intrusion Prevention System Sensor CLI Configuration Guide for IPS 5.0
17-20
Manually upgrade the boot loader
You must first boot to the old helper file where there is an option to update the boot loader in the
helper menu. Then you reboot and reimage the hard-disk drive. Refer to in the 4.x documentation.
You no longer need to boot to the helper to load the 5.0 system image. The 5.0 system image contains
everything needed to reimage the NM-CIDS.
The new bootloader works with the 4.x system image; however, you must boot to the helper to load
it.
Upgrading the Bootloader, page
Obtaining Cisco IPS Software, page
Make sure you can access the TFTP server location from the network connected to your
NM-CIDS' Ethernet port.
Chapter 17 Upgrading, Downgrading, and Installing System Images
17-22.
