In the top of the device window open the path "Parameters" > "Interfaces" by clicking on the
relevant plus signs, and then select
In call windows 1 to 4 set start and end to the same value for each one and then select the
"Transfer changes to device" icon at the top of the enSuite window.
Then wait a minute, for any communications activity in progress on the EK205-M to be safely
stopped.
b) Sending parameter file
Send the following parameter file to the EK205-M ( section
ECM-2G-UG350:
For the following customized settings and tests required, press "Navigation" on the left-hand side
and then
"Parameterize
i
All the values listed in enSuite under "Parameters" can be found on the "Serv." display tab of
the EK205-M under the same path. However, it is not possible to enter the following APN data
via keyboard but must be entered via the enSuite parameterization software.
c) Configure individual parameters
In the top of the device window open the path "Parameters" > "Interfaces" > "
by clicking on the relevant plus signs, and then select
On the right-hand side of the window you will now see several values, in which the following must
be entered:
Value
GPRS access point name "APN"
APN user name "UName"
APN password "PwAPN"
IP port "Port"
GPRS authentication protocol
"AutPr"
i
If you fail to input an Access Point Name (APN), the APN that is saved on the SIM is used.
Since this is usually a public APN (no access to a VPN) and since a dynamic IP address is
allocated when a GPRS session with a public APN is set up, the TCP server function cannot
be used! This is because a static IP address would be needed for this purpose. In such a case,
the modem could only be used as TCP client.
Caution!
Without the input of an APN there is the risk that unspecified costs may be incurred, as with
every set up through a GPRS provider and based on a corresponding tariff a minimum data
volume (e.g., 10 or 100 kB) will be billed!
Press the
"Transfer changes to
If required (i.e. with the aid of the enSuite user list) two further addresses for a "Domain Name
System" can be entered in addresses 3:0794.0 and 3:0795.0. This is however not essential.
d) Setting time window for potential data retrievals
In the base configuration now displayed you can define time windows, during which data can be
retrieved cyclically from the EK205-M via the modem. There are two available time windows. One
which operate on EK205-M basic device battery power only and the other for versions of the
EK205-M with external power supply for basic device.
"Call time
EK205_1v07.. - int. ECM-2G-UG350 TCPServ.wpp
online" at the bottom of the navigation window.
These values vary according to the SIM card and VPN (Virtual
Private Network) in use. The values to be entered can normally be
obtained from your IT department or SIM card provider.
"Port" means the TCP port no. of the retrieval system in use.
0 =
None
1 =
CHAP
(default)
2 =
PAP
device" icon at the top of the enSuite window.
windows".
7.6 Send parameter
"GSM and
GPRS".
Input
Depending on the provider, the protocols
specified on the left can be used to log on to
the GPRS network. Consultation with the
provider may be required.
Data transfer
file, p. 51):
Terminal
Interfaces"
