The DTMFSend commands
xCommand DTMFSend
Send DTMF tones to the far end.
CallId: The CallID is returned when the xCommand Dial command is run. During the call you can run the
xStatus Call command to see the CallId.
DTMFString: Enter the DTMF string.
Requires user role: USER
Parameters:
CallId: <0..65534>
DTMFString(r): <S: 0, 32>
example:
xCommand DTMFSend CallId:2 DTMFString:1234
*r DTMFSendResult (status=OK):
** end
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration
The FacilityService commands
xCommand FacilityService Dial
82
xCommand xCommand
Dial out from the system to a facility service. A maximum of five facility services can be defined; which
one of these five to dial to is identified by the ServiceId (ref. xConfiguration Facility Service [ServiceId]
Type/Name/Number/CallType). The command returns information about the CallId and ConferenceId.
ServiceId: The identifier of the facility service.
Requires user role: USER
Parameters:
ServiceId(r): <1..5>
example:
xCommand FacilityService Dial ServiceId: 1
OK
*r FacilityServiceDialResult (status=OK):
CallId: 2
ConferenceId: 1
** end
