Cisco Codec C20 Reference Manual page 62

Cisco TelePresence System Codec C20
Contents Introduction
xConfiguration Video PIP ActiveSpeaker DefaultValue Position
Determine the position on screen of the active speaker picture-in-picture (PiP). The setting only takes
effect when using a video layout where the active speaker is a PiP, i.e. the Overlay layout, or possibly
a Custom layout (see the Video Layout LocalLayoutFamily setting). The setting takes effect from the
next call onwards; if changed during a call, it will have no effect on the current call.
Requires user role: ADMIN
Value space: <Current/UpperLeft/UpperCenter/UpperRight/CenterLeft/CenterRight/
LowerLeft/LowerRight>
Current: The position of the active speaker PiP will be kept unchanged when leaving a call.
UpperLeft: The active speaker PiP will appear in the upper left corner of the screen.
UpperCenter: The active speaker PiP will appear in the upper center position.
UpperRight: The active speaker PiP will appear in the upper right corner of the screen.
CenterLeft: The active speaker PiP will appear in the center left position.
CentreRight: The active speaker PiP will appear in the center right position.
LowerLeft: The active speaker PiP will appear in the lower left corner of the screen.
LowerRight: The active speaker PiP will appear in the lower right corner of the screen.
example: xConfiguration Video PIP ActiveSpeaker DefaultValue Position: Current
xConfiguration Video PIP Presentation DefaultValue Position
Determine the position on screen of the presentation picture-in-picture (PiP). The setting only takes
effect when the presentation is explicitly minimized to a PiP, for example using the remote control or
the Touch controller. The setting takes effect from the next call onwards; if changed during a call, it
will have no effect on the current call.
Requires user role: ADMIN
Value space: <Current/UpperLeft/UpperCenter/UpperRight/CenterLeft/CenterRight/
LowerLeft/LowerRight >
Current: The position of the presentation PiP will be kept unchanged when leaving a call.
UpperLeft: The presentation PiP will appear in the upper left corner of the screen.
UpperCenter: The presentation PiP will appear in the upper center position.
UpperRight: The presentation PiP will appear in the upper right corner of the screen.
CenterLeft: The presentation PiP will appear in the center left position.
CentreRight: The presentation PiP will appear in the center right position.
LowerLeft: The presentation PiP will appear in the lower left corner of the screen.
LowerRight: The presentation PiP will appear in the lower right corner of the screen.
example: xConfiguration Video PIP Presentation DefaultValue Position: Current
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration xConfiguration
62
xCommand
xConfiguration Video Layout LocalLayoutFamily
Select which video layout family to use locally.
Requires user role: ADMIN
Value space: < A u t o/ F u l l S c r e e n / E q u a l / P r e s e n t a t i o n S m a l l S p e a k e r/
PresentationLargeSpeaker/Prominent/Overlay/Single>
Auto: The default layout family, as given by the layout database, will be used as the local layout. For
more information about the layout database, see the xCommand Video Layout LoadDb command.
FullScreen: The FullScreen layout family will be used as the local layout. It means that the active
speaker or presentation will be shown in full screen. Using this value is not recommended as
from TC6.0.
Equal: The Equal layout family will be used as the local layout. All videos have equal size, as long
as there is space enough on the screen.
PresentationSmallSpeaker: The PresentationSmallSpeaker layout family will be used as the local
layout. Using this value is not recommended as from TC6.0.
PresentationLargeSpeaker: The PresentationLargeSpeaker layout family will be used as the local
layout. Using this value is not recommended as from TC6.0.
Prominent: The Prominent layout family will be used as the local layout. The active speaker, or the
presentation if present, will be a large picture, while the other participants will be small pictures.
Transitions between active speakers are voice switched.
Overlay: The Overlay layout family will be used as the local layout. The active speaker, or the
presentation if present, will be shown in full screen, while the other participants will be small
pictures-in-picture (PiP). Transitions between active speakers are voice switched.
Single: The active speaker, or the presentation if present, will be shown in full screen. The other
participants are not shown. Transitions between active speakers are voice switched.
example: xConfiguration Video Layout LocalLayoutFamily: Auto
API Reference Guide
xStatus Appendices
Copyright © 2010–2013 Cisco Systems, Inc. All rights reserved.
