Contents Introduction
Conference configuration
xConfiguration Conference [1..1] AutoAnswer Mode
Set the auto answer mode.
Requires user role: ADMIN
Value space: <Off/On>
Off: An incoming call must be answered manually by pressing the OK key or the green Call key on
the remote control, or by tapping the Accept key on the Touch controller..
On: Enable auto answer to let the system automatically answer all incoming calls.
example: xConfiguration Conference 1 AutoAnswer Mode: Off
xConfiguration Conference [1..1] AutoAnswer Mute
Determine if the microphone shall be muted when an incoming call is automatically answered. NOTE:
Requires that AutoAnswer Mode is switched on.
Requires user role: ADMIN
Value space: <Off/On>
Off: The incoming call will not be muted.
On: The incoming call will be muted when automatically answered.
example: xConfiguration Conference 1 AutoAnswer Mute: Off
xConfiguration Conference [1..1] AutoAnswer Delay
Define how long (in seconds) an incoming call has to wait before it is answered automatically by the
system. NOTE: Requires that AutoAnswer Mode is switched on.
Requires user role: ADMIN
Value space: <0..50>
Range: Select a value from 0 to 50 seconds.
example: xConfiguration Conference 1 AutoAnswer Delay: 0
xConfiguration Conference [1..1] MicUnmuteOnDisconnect Mode
Determine if the microphones shall be unmuted automatically when all calls are disconnected. In a
meeting room or other shared resources this may be done to prepare the system for the next user.
Requires user role: ADMIN
Value space: <Off/On>
Off: If muted during a call, let the microphones remain muted after the call is disconnected.
On: Unmute the microphones after the call is disconnected.
example: xConfiguration Conference 1 MicUnmuteOnDisconnect Mode: On
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration xConfiguration
xConfiguration Conference [1..1] DoNotDisturb Mode
xConfiguration Conference [1..1] DoNotDisturb DefaultTimeout
xConfiguration Conference [1..1] FarendControl Mode
32
xCommand
Determine if there should be an alert on incoming calls.
Requires user role: USER
Value space: <Off/On/Timed>
Off: The incoming calls will come through as normal.
On: All incoming calls will be rejected and they will be registered as missed calls. The calling side
will receive a busy signal. A message telling that Do Not Disturb is switched on will display on the
Touch controller or main display. The calls received while in Do Not Disturb mode will be shown as
missed calls.
Timed: Select this option only if using the API to switch Do Not Disturb mode on and off (xCommand
Conference DoNotDisturb Activate and xCommand Conference DoNotDisturb Deactivate).
example: xConfiguration Conference 1 DoNotDisturb Mode: Off
This setting determines the default duration of a Do Not Disturb session, i.e. the period when incoming
calls are rejected and registered as missed calls. The session can be terminated earlier by using the
user interface (remote control or Touch controller) or the Conference DoNotDisturb Mode setting. The
default value is 60 minutes.
Requires user role: ADMIN
Value space: <0..1440>
Range: Select the number of minutes (between 0 and 1440, i.e. 24 hours) before the Do Not Disturb
session times out automatically.
example: xConfiguration Conference 1 DoNotDisturb DefaultTimeOut: 60
Lets you decide if the remote side (far end) should be allowed to select your video sources and control
your local camera (pan, tilt, zoom).
Requires user role: ADMIN
Value space: <Off/On>
Off: The far end is not allowed to select your video sources or to control your local camera (pan,
tilt, zoom).
On: Allows the far end to be able to select your video sources and control your local camera (pan,
tilt, zoom). You will still be able to control your camera and select your video sources as normal.
example: xConfiguration Conference 1 FarEndControl Mode: On
