The Camera commands
xCommand Camera PanTiltReset
The camera is reset to its default values for pan and tilt. If the camera is daisy chained, the CameraId
is given by its place in the chain.
Requires user role: USER
Parameters:
CameraId(r): <1..1>
example:
xCommand Camera PanTiltReset CameraId:1
OK
*r PanTiltResetResult (status=OK):
** end
xCommand Camera PositionReset
Reset the camera position the the deafult position.
Requires user role: USER
Parameters:
CameraId(r): <1..1>
example:
xCommand Camera PositionReset CameraId:1
OK
*r CameraPositionResetResult (status=OK):
** end
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration
xCommand Camera PositionSet
77
xCommand xCommand
Position the camera by defining the pan, tilt, zoom and focus parameters. If the camera is placed in a
daisy chain you need to know the CameraId for the camera you want to address.
Requires user role: USER
Parameters:
CameraId(r): <1..1>
Pan: <-65535..65535>
Tilt: <-65535..65535>
Zoom: <0..65535>
Focus: <0..65535>
example:
xCommand Camera PositionSet CameraId:1 Pan:200 Tilt:300
OK
*r CameraPositionSetResult (status=OK):
** end
