Cisco TelePresence System Codec C20
Contents Introduction
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTCP Local
IpAddress
Shows the local IP address of the Real-time Transport Control Protocol (RTCP) port for the incoming
audio in the media channel.
Value space of the result returned:
<String>
example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Local
IpAddress
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Local IpAddress:
"192.168.24.190"
** end
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTCP Local Port
Shows the local UDP port number of the Real-time Transport Control Protocol (RTCP) port for the
incoming audio in the media channel.
Value space of the result returned:
<Integer>
example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Local Port
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Local Port:
16405
** end
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RTCP Remote
IpAddress
Shows the remote IP address of the Real-time Transport Control Protocol(RTCP) port for the incoming
audio in the media channel.
Value space of the result returned:
<String>
example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Remote
IpAddress
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Remote
IpAddress: "192.168.136.130"
** end
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration
xStatus MediaChannels Call [1..n] IncomingAudioChannel [1..n] Transport RCTP Remote Port
xStatus MediaChannels Call [1..n] IncomingVideoChannel [1..n] encryption Status
xStatus MediaChannels Call [1..n] IncomingVideoChannel [1..n] ChannelRole
128
xCommand
Shows the remote UDP port number of the Real-time Transport Control Protocol(RTCP) port for the
incoming audio in the media channel.
Value space of the result returned:
<Integer>
example:
xStatus MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Remote Port
*s MediaChannels Call 27 IncomingAudioChannel 327 Transport RTCP Remote Port:
50933
** end
Shows the encryption status on the incoming channel.
Value space of the result returned:
<On/Off>
example:
xStatus MediaChannels Call 27 IncomingVideoChannel 330 Encryption Status
*s MediaChannels Call 27 IncomingVideoChannel 330 Encryption Status: Off
** end
Shows if the incoming channel is the main video channel or presentation channel.
Value space of the result returned:
<Main/Presentation>
example:
xStatus MediaChannels Call 27 IncomingVideoChannel 330 ChannelRole
*s MediaChannels Call 27 IncomingVideoChannel 330 ChannelRole: Main
** end
