Cisco TelePresence System Codec C20
Contents Introduction
Audio configuration
xConfiguration Audio Microphones Mute enabled
Determine whether audio-mute is allowed or not. The default value is True.
Requires user role: ADMIN
Value space: <True/InCallOnly>
True: Muting of audio is always available.
InCallOnly: Muting of audio is only available when the device is in a call. When Idle it is not possible to
mute the microphone. This is useful when an external telephone service/audio system is connected
via the codec and is to be available when the codec is not in a call. When set to InCallOnly this will
prevent the audio-system from being muted by mistake.
example: xConfiguration Audio Microphones Mute Enabled: True
xConfiguration Audio SoundsAndAlerts KeyTones Mode
The system can be configured to make a keyboard click sound effect (key tone) when pressing a key
on the remote control, or when typing text or numbers on a Touch controller.
Requires user role: USER
Value space: <Off/On>
Off: No key tones will be played when you type.
On: You will hear a key tone when you press a key or type text.
example: xConfiguration Audio SoundsAndAlerts KeyTones Mode: Off
xConfiguration Audio SoundsAndAlerts RingTone
Select the ring tone for incoming calls.
Requires user role: USER
Value space: <Marbles/IceCrystals/Polaris/Alert/Discreet/Fantasy/Jazz/Nordic/
Echo/Rhythmic>
Range: Select a tone from the list of ring tones.
example: xConfiguration Audio SoundsAndAlerts RingTone: Jazz
xConfiguration Audio SoundsAndAlerts RingVolume
Sets the ring volume for an incoming call.
Requires user role: USER
Value space: <0..100>
Range: The value goes in steps of 5 from 0 to 100 (from -34.5 dB to 15 dB). Volume 0 = Off.
example: xConfiguration Audio SoundsAndAlerts RingVolume: 50
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration xConfiguration
xConfiguration Audio Volume
29
xCommand
Adjust the speaker volume.
Requires user role: USER
Value space: <0..100>
Range: The value must be between 0 and 100. The values from 1 to 100 correspond to the range
from -34.5 dB to 15 dB (0.5 dB steps). The value 0 means that the audio is switched off.
example: xConfiguration Audio Volume: 70
