Cisco TelePresence System Codec C20
Contents Introduction
xCommand Camera Ramp
Move the camera in a specified direction. The camera moves at specified speed until a stop command
is issued. In a daisy chain, you need to know the CameraId for the camera you want to address. Be
aware that pan and tilt can be operated simultaneously, but no other combinations. In the latter case
only the first operation specified is executed. For example, if you try to run both zoom and pan at the
same time, only zoom is executed.
NOTE: You must run a stop command to stop the camera, see the example below.
CameraId: Give the camera id.
Pan: Move the camera to the Left or Right, followed by Stop.
PanSpeed: Set the pan speeed.
Tilt: Move the camera Up or Down, followed by Stop.
TiltSpeed: Set the tilt speeed.
Zoom: Zoom the camera In or Out, followed by Stop.
ZoomSpeed: Set the zoom speeed.
Focus: Focus the camera Far or Near, followed by Stop.
Requires user role: USER
Parameters:
CameraId(r): <1..1>
Pan: <Left/Right/Stop>
PanSpeed: <1..15>
Tilt: <Down/Up/Stop>
TiltSpeed: <1..15>
Zoom: <In/Out/Stop>
ZoomSpeed: <1..15>
Focus: <Far/Near/Stop>
example:
xCommand Camera Ramp CameraId:1 Pan:left PanSpeed:1
OK
*r RampResult (status=OK):
** end
xCommand Camera Ramp CameraId:1 Pan:stop
OK
*r RampResult (status=OK):
** end
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration
xCommand Camera TriggerAutofocus
xCommand Camera PositionActivateFromPreset
78
xCommand xCommand
Trigger the autofocus functionality. The camera must support autofocus functionality. If the camera is
daisy chained, the CameraId is given by its place in the chain.
Requires user role: USER
Parameters:
CameraId(r): <1..1>
example:
xCommand Camera TriggerAutofocus CameraId:1
OK
*r TriggerAutofocusResult (status=OK):
** end
Selects pan, tilt, zoom and focus parameters for the given camera id from the selected preset.
CameraId: Give the camera id.
PresetId: Select preset 1 to 15.
Requires user role: USER
Parameters:
CameraId(r): <1..1>
PresetId(r): <1..15>
example:
xCommand Camera PositionActivateFromPreset CameraId:1 PresetID:1
OK
*r PositionActivateFromPresetResult (status=OK):
** end
