xConfiguration FacilityService Service [1..5] Number
Set the number for each facility service. Up to five different facility services are supported.
A facility service is not available unless both the FacilityService Service Name and the FacilityService
Service Number settings are properly set.
Only FacilityService Service 1 is available on the Touch controller. Facility services are not available
when using the remote control and on-screen menu.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
example: xConfiguration FacilityService Service 1 Number: ""
xConfiguration FacilityService Service [1..5] CallType
Set the call type for each facility service. Up to five different facility services are supported.
A facility service is not available unless both the FacilityService Service Name and the FacilityService
Service Number settings are properly set.
Only FacilityService Service 1 is available on the Touch controller. Facility services are not available
when using the remote control and on-screen menu.
Requires user role: ADMIN
Value space: <Video/Audio>
Video: Select this option for video calls.
Audio: Select this option for audio calls.
example: xConfiguration FacilityService Service 1 CallType: Video
Codec C20 API Reference Guide TC6.0 February 2013.
D14869.05
About the API xConfiguration xConfiguration
H323 configuration
xConfiguration H323 NAT Mode
xConfiguration H323 NAT Address
xConfiguration H323 Profile [1..1] Authentication Mode
36
xCommand
The firewall traversal technology creates a secure path through the firewall barrier, and enables proper
exchange of audio/video data when connected to an external video conferencing system (when the IP
traffic goes through a NAT router). NOTE: NAT does not work in conjunction with gatekeepers.
Requires user role: ADMIN
Value space: <Auto/Off/On>
Auto: The system will determine if the "NAT Address" or the real IP-address should be used in
signalling. This is done to make it possible to place calls to endpoints on the LAN as well as endpoints
on the WAN.
Off: The system will signal the real IP Address.
On: The system will signal the configured "NAT Address" instead of its own IP-address in Q.931 and
H.245. The NAT Server Address will be shown in the startup-menu as: "My IP Address: 10.0.2.1".
example: xConfiguration H323 NAT Mode: Off
Enter the external/global IP-address to the router with NAT support. Packets sent to the router will then
be routed to the system.
In the router, the following ports must be routed to the system's IP-address:
* Port 1720
* Port 5555-5574
* Port 2326-2485
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
example: xConfiguration H323 NAT Address: ""
Set the authenticatin mode for the H.323 profile.
Requires user role: ADMIN
Value space: <Off/On>
Off: If the H.323 Gatekeeper Authentication Mode is set to Off the system will not try to authenticate
itself to a H.323 Gatekeeper, but will still try a normal registration.
On: If the H.323 Gatekeeper Authentication Mode is set to On and a H.323 Gatekeeper indicates that
it requires authentication, the system will try to authenticate itself to the gatekeeper. NOTE: Requires
the Authentication LoginName and Authentication Password to be defined on both the codec and
the Gatekeeper.
example: xConfiguration H323 Profile 1 Authentication Mode: Off
