Draytek Vigor2860 User Manual page 291

Below shows Wireless LAN>>WPS web page:
Available settings are explained as follows:
Item
Enable WPS
WPS Status
SSID
Authentication Mode
Configure via Push Button
Configure via Client
PinCode
Vigor2860 Series User's Guide
Description
Check this box to enable WPS setting.
Display related system information for WPS. If the wireless
security (encryption) function of the router is properly
configured, you can see 'Configured' message here.
Display the SSID1 of the router. WPS is supported by SSID1
only.
Display current authentication mode of the router. Only
WPA2/PSK and WPA/PSK support WPS.
Click Start PBC to invoke Push-Button style WPS setup
procedure. The router will wait for WPS requests from
wireless clients about two minutes. The WPS LED on the
router will blink fast when WPS is in progress. It will return to
normal condition after two minutes. (You need to setup WPS
within two minutes)
Please input the PIN code specified in wireless client you
wish to connect, and click Start PIN button. The WPS LED on
the router will blink fast when WPS is in progress. It will
return to normal condition after two minutes. (You need to
setup WPS within two minutes)
277
