After finishing all the settings here, please click OK to activate them.
I I - 1 - 2 - 4 D
I I - 1 - 2 - 4 D
A D S L )
A D S L )
MPoA is a specification that enables ATM services to be integrated with existing LANs, which
use either Ethernet, token-ring or TCP/IP protocols. The goal of MPoA is to allow different
LANs to send packets to each other via an ATM backbone.
To use MPoA/Static or Dynamic IP as the accessing protocol of the Internet, select MPoA
/Static or Dynamic IP from the WAN>>Internet Access >>WAN1 page. The following web
page will appear.
Vigor2860 Series User's Guide
Fixed IP – Click Yes to use this function and type in a fixed IP
address in the box of Fixed IP Address.
Default MAC Address – You can use Default MAC Address or
specify another MAC address by typing on the boxes of MAC
Address for the router.
Specify a MAC Address – Type the MAC address for the router
manually.
Index (1-15) in Schedule Setup - You can type in four sets of
time schedule for your request. All the schedules can be set
previously in Applications >> Schedule web page and you
can use the number that you have set in that web page.
e t a i l s P a g e f o r M P o
e t a i l s P a g e f o r M P o
A / S t a t i c o r D y n a m i
A / S t a t i c o r D y n a m i
c I P i n W A N 1 ( P h y s i
c I P i n W A N 1 ( P h y s
c a l M o d e :
i c a l M o d e :
89
