C r e a t i n g
C r e a t i n g
1. Select a number index and click Edit to open the following web page.
Available settings are explained as follows:
Item
Location (Profile Name)
Upload Map
Cancel
Next
2. Click Next. In the web page of Dimension, set dimension for the map.
Vigor2862 Series User's Guide
/ E d i t i n g t h e A P M a p P
/ E d i t i n g t h e A P M a p P
r o f i l e
r o f i l e
Description
Type a name (e.g., 3F) for the AP map profile.
Click the Select button to choose an image file (only JPG
and PNG are supported) for floor plan.
Click it to cancel the configuration.
Click it to go to the next configuration page.
619
