Hardware
Acceleration
Ethernet Type
Local Address
Remote Address
DiffServ CodePoint
Service Type
4. After finishing all the settings here, please click OK to save the configuration.
By the way, you can set up to 20 rules for one Class. If you want to edit an existed rule, please
select the radio button of that one and click Edit to open the rule edit page for modification.
Vigor2862 Series User's Guide
Check this box to enable the hardware acceleration when
such rule is applied.
Please specify which protocol (IPv4 or IPv6) will be used for
this rule.
Click the Edit button to set the local IP address (on LAN) for
the rule.
Click the Edit button to set the remote IP address (on
LAN/WAN) for the rule.
Address Type – Determine the address type for the source
address.
For Single Address, you have to fill in Start IP address.
For Range Address, you have to fill in Start IP address and
End IP address.
For Subnet Address, you have to fill in Start IP address and
Subnet Mask.
All the packets of data will be divided with different levels
and will be processed according to the level type by the
system. Please assign one of the levels of the data for
processing with QoS control.
It determines the service type of the data for processing with
QoS control. It can also be edited. You can choose the
predefined service type from the Service Type drop down
list. Those types are predefined in factory. Simply choose the
one that you want for using by current QoS.
