WAN Connection
Detection
RIPng Protocol
Bridge Mode
After finished the above settings, click OK to save the settings.
I I - 1 - 2 - 1 7
I I - 1 - 2 - 1 7
This type allows you to setup static IPv6 address for WAN interface.
114
Such function allows you to verify whether network
connection is alive or not through NS Detect or Ping Detect.
Mode – Choose Always On, Ping Detect or NS Detect for
the system to execute for WAN detection. With NS Detect
mode, the system will check if network connection is
established or not, like IPv4 ARP Detect. Always On means
no detection will be executed. The network connection will
be on always.


RIPng (RIP next generation) offers the same functions and
benefits as IPv4 RIP v2.
Enable Bridge Mode - If the function is enabled, the router
will work as a bridge modem.
Enable Firewall – It is available when Bridge Mode is
enabled. When both Bridge Mode and Firewall check boxes
are enabled, the settings configured (user profiles) under
User Management will be ignored. And all of the filter rules
defined and enabled in Firewall menu will be activated.
Bridge Subnet – Make a bridge between the selected LAN
subnet and such WAN interface.
D e t a i l s P a g e f o r I P v
D e t a i l s P a g e f o r I P v
Realm – The name (1 to 31 characters) typed here will
identify the key which generates HMAC-MD5 value.
Secret – Type a text (1 to 31 characters) as s a unique
identifier for each client on each DHCP server.
Ping IP/Hostname – If you choose Ping Detect as
detection mode, you have to type IP address in this field
for pinging.
TTL (Time to Live) –If you choose Ping Detect as
detection mode, you have to type TTL value.
6 S t a t i c I P v 6 i n W
6 S t a t i c I P v 6 i n W
–
–
A N 1 / W A N 2
A N 1 / W A N 2
Vigor2862 Series User's Guide
