4 . 7 . 3 I G M P P r o
4 . 7 . 3 I G M P P r
IGMP is the abbreviation of Internet Group Management Protocol. It is a communication
protocol which is mainly used for managing the membership of Internet Protocol multicast
groups.
Available parameters are listed as follows:
Item
Enable
IGMP Proxy Channel
Downstream
Apply
Cancel
4 . 7 . 4 U P n P
4 . 7 . 4 U P n P
The UPnP (Universal Plug and Play) protocol is supported to bring to network connected
devices the ease of installation and configuration which is already available for directly
connected PC peripherals with the existing Windows 'Plug and Play' system. For NAT
routers, the major feature of UPnP on the router is "NAT Traversal". This enables
applications inside the firewall to automatically open the ports that they need to pass through
a router. It is more reliable than requiring a router to work out by itself which ports need to
be opened. Further, the user does not have to manually set up port mappings or a DMZ.
UPnP is available on Windows XP and the router provide the associated support for MSN
Messenger to allow full use of the voice, video and messaging features.
Vigor2960 Series User's Guide
x y
o x y
Description
Check this box to enable IGMP proxy function.
The application of multicast will be executed through WAN
port. In addition, such function is available in NAT mode.
Use the drop down list to specify the LAN profile as the
destination of data coming from WAN interface (defined in
IGMP Proxy Channel).
Click it to save the configuration.
Click it to discard the settings configured in this page.
