Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
582
Press the "Scaling" softkey.
The "Scaling" input window opens.
- OR -
Press the "Mirroring" softkey.
The "Mirroring" input window opens.
- OR -
Press the "Rotation C axis" softkey.
The "Rotation C axis" input window opens.
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Turning
