Reading Max. /Min. Numeric Calculation (%C)
Read Min./Max. Numeric Calculation (01 to 99). The numeric calculation of the currently selected product
type in AX40 can be read.
Serial Settings - Command Digit: "Valid"
Communication Command / Description
direction
Sending command
from external
device
?? : 01 - 99 (To specify Numeric Calculation No.)
Response-At
normal operation
?? : 01 - 99 (Numeric Calculation No.)
Min.: - 2147483648 - 2147483647
Max.: - 2147483648 - 2147483647
% U CR
Response- Error 1
Cause
•
Response- Error 2
ERROR signal is
output from the
Cause
parallel output port.
The checker number specified by a sending command is not between 01 and 99
Command Digit: Fixed (4 Digit)
Communication Command / Description
direction
% C ?
Sending command
from external
device
?? : 01 - 99 (Numeric Calculation No.)
% C ?
Response-At
normal operation
??:01 - 99 (Numeric calculation No.)
Min.: Fixed (12 Digit)
(- 02147483648 to 002147483647 or - 2147483648 to
Max: Fixed (12 Digit)
(- 02147483648 to 002147483647 or - 2147483648 to
Response- Error
Cause
The checker number specified by the sending command is not between 01 and 99.
• To specify the command digit (valid/fixed (4 Digit)), select "ENVIRONMENT" > "Serial
Settings" > "Command Digit" from the menu bar.
• The AX40 can read more than 5-digit data, even if "Fixed (4-Digit) is selected.
% C ? ? CR
% C ? ? , Min.
Command in the unspecified form or not provided was received.
Examples:
C
- %C3 (any other numeric calculation number than 01 to 96 was specified)
R
C
- %B03 (not provided command)
R
% Z CR
? CR
? Min.
- 02147483648 to 002147483647: If invalid digit =0
- 02147483648 to 002147483647: If invalid digit =space
% U CR
, Max. CR
Max. CR
2147483647)
2147483647)
