Muffler Replacement

Removal Procedure
1. Raise and support the vehicle. Refer to "Lifting and
Jacking the Vehicle: ".
2. Loosen the exhaust muffler clamps.
3. With the aid of an assistant, separate the rubber
insulators from the exhaust pipe hangers.
4. With the aid of an assistant, remove the muffler
assembly from exhaust flexible pipe and the vehicle.
Installation Procedure
1. With the aid of an assistant, install the muffler
assembly to the vehicle and the exhaust flexible
pipe.
2. With the aid of an assistant, install the exhaust pipe
hangers to the rubber insulators.
CAUTION
!
Refer to "Fastener Notice: ".
3. Tighten the exhaust muffler clamps.
Tightening torque
Tighten the clamps to 5 N⋅m (44 lb in).
4. Lower the vehicle.
Exhaust System: 1K-16
