device, but a 2

and other devices are also provided in the ASEQ function. We

have omitted the Element IDs and their names for the other devices to improve

readability. Use the rule described below when the user wishes to obtain the

Element IDs and their names for the other devices.

Rule: The same types of signal monitoring points are provided in every device;

hence, the user can find the same ones for all of the other devices. For

example, when the user wishes to find the "ASEQ01_EC_LCD" point for

device, use the description of "ASEQ02_EC_LCD" in place of

"ASEQ01_EC_LCD". The user can obtain the ID value of

"ASEQ02_EC_LCD" by using the following steps:

Find the element ID for ASEQ01_EC_LCD (i.e.,

"800D011D58")

Identify the number at the fifth digit from the ID. (i.e., "1")

Choose a new device number. (i.e., pick the number "2" for

Replace the number that occurs at the fifth digit with the

new device number. (i.e., get new ID "800D021D58" of

"ASEQ02_EC_LCD") The ID is expressed in hexadecimal

notation. Thus, the user must change the device number

from decimal notation to hexadecimal notation.

6F2S1915 (0.46)

GRZ200 (Soft 031 & 032)
