3. Transmission and receiving (Full duplex mode)
When full duplex mode is used, set the receive interrupt level to 0, and only set
the interrupt level (from 1 to 6) of the transmit interrupt. Ensure that the
program which transmits the interrupt reads the receiving buffer before setting
the next transmit data.
The following is an example of this:
Example: Channel 0, SCLK output
Baud rate = 9600 bps
fc = 4.9152 MHz
Main routine
7 6
INTES0 X 0
PFCR X X
−
PFFC X
− −
SC0MOD0
−
SC0MOD1 1
− −
SC0CR
BR0CR 0 0
− −
SC0MOD0
SC0BUF
* *
INTTX0 interrupt routine
← SC0BUF
A
CC
SC0BUF * *
X: Don't care, −: No change
*Clock condition: Clock gear 1/1(fc)
5 4 3 2 1 0
0 1 X 0 0 0 Set the INTTX0 level to 1.
Set the INTRX0 level to 0.
X X X 1 0 1 Set PF0, PF1 and PF2 to function as the TXD0,
RXD0 and SCLK0 pins respectively.
X X X 1 0 1
− − − −
0 0 Select I/O interface mode.
X X X X X X Select full duplex mode.
− − − −
0 0 SCLK output, transmit on negative edge, receive
on positive edge.
Baud rate = 9600 bps.
0 1 1 0 0 0
− − − − −
1 Enable receiving.
Set the transmit data and start.
* * * * * *
Read the receiving buffer.
* * * * * * Set the next transmit data.
