Up.Speed = InputInt("Confirm the speed.", $(Up.n))
Figure 4-90
4.6.10.8

InputReal

InputReal("<label>", <real>)
The InputReal() function displays a dialog box in which during package execution the user
can enter a real number.
This real value is assigned to an Up variable.
● The entry can be explained using the <label> argument.
● The <real> argument must contain a default value. This can be changed while the
package is being executed.
The following entries are permitted:
● The return value is the number that the user had entered.
Example of real-number entry
Up.RealNumber = InputReal("Enter a real number", 567.890)
Figure 4-91
SINUMERIK Integrate Create MyConfig - Diff, Expert, Topo
Operating Manual, 12/2017, A5E36537479B-AE
Example of replacement from STRING, e.g. Enum (enumeration)
Decimal:
Exponential:
Example of real-number entry
-15 = -15
1.5 = 1.5
1.5e2 = 150
1.5ex+2 = 150
-1.5ex-2 = -0.015
Create MyConfig - Expert
4.6 Script language
317
