Siemens Sinamics S120 Function Manual page 187

Byte Bi t
2 0 ... 2
3
4, 5
6
7
3 0
1
2
3
4
5
6
7
Only valid for CU310-2.
1)
Safety Integrated
Function Manual, (FHS), 07/2016, 6SL3097-4AR00-0BP6
Me a n i n g
Reserved
SLP active position range
Reserved
Safe position valid
Safely referenced
F-DI 0
1)
F-DI 1
1)
F-DI 2
1)
Reserved
SS2E active
SOS selected
SLP upper limit maintained
SLP lower limit maintained
C o m m e n ts
– –
1 SLP area 2 (SLP2) active
0 SLP area 1 (SLP1) active
– The status signal "SLP active position range"
always corresponds to the diagnostic signal
"SLP active position range" (r9722.19).
– –
1 Safe position valid
0 Safe position invalid
1 Safe position is applicable as "safely refer-
enced"
0 Safe position is not applicable as "safely refer-
enced"
1 F-DI 0 inactive
0 F-DI 0 active
1 F-DI 1 inactive
0 F-DI 1 active
1 F-DI 2 inactive
0 F-DI 2 active
– –
1 SS2E active
0 SS2E not active
1 SOS selected
0 SOS deselected
1 SLP: Upper limit maintained
0 SLP: Upper limit not maintained
– The status signal "upper SLP limit maintained"
always corresponds to the diagnostic signal
"upper SLP limit maintained" (r9722.30).
1 SLP: Lower limit maintained
0 SLP: Lower limit not maintained
– The status signal "lower SLP limit maintained"
always corresponds to the diagnostic signal
"lower SLP limit maintained" (r9722.31).
Control of the safety functions
5.3 Activation via PROFIsafe
187
