226 | © 2013 ABB | 1SDH001000R0002 - L7804
YO-YC-YO2-YC2: Connections
Further information is available on page 156, or on the site http://www.abb.com/abblibrary/
DownloadCenter/, where the wiring diagram is available 1SDM000091R0001.
Diagrams 75 - 72 - 77 - 79
Information on assembly is available at the web site http://www.abb.com/abblibrary/
DownloadCenter/, in particular with the sheets kit:
•
1SDH001000R0502
for YO and YO2 coils
•
for YC and YC2 coils
1SDH001000R0503
Electrical accessories | 1 - Electrical Control accessories
ABB | SACE Emax 2
