1.8 UBIC-V Cables

Figure 1-24

75Ω Signal
To/From UBIC-V
75Ω Signal
To/From UBIC-V
To/From SCSI
connector on the
UBIC-V EIA
75Ω Signal
To/From UBIC-V
75Ω Signal
To/From UBIC-V
Table 1-17
Cisco ONS 15454 Reference Manual, R8.5
1-42

UBIC-V DS-1 Cable Schematic Diagram

UBIC-V DS-1 Cable
DS1 75Ω
Pin 1
Port #1
FGND
Pin 2 — FGnd
Pin 3 — FGnd
Pin 4 — FGnd
DS1 75Ω
Pin 5
Port #2
FGND
DS1 75Ω
Pin 25
Port #13
FGND
DS1 75Ω
Pin 50
Port #14
FGND
shows the UBIC-V DS-1 Tip/Ring color coding.
Chapter 1
Shield to connector shell
1:1.15
Tip DS1 #1
Ring DS1 #1
1:1.15
Tip DS1 #2
Ring DS1 #2
Shield to connector shell
1:1.15
Tip DS1 #13
Ring DS1 #13
1:1.15
Tip DS1 #14
Ring DS1 #14
Shelf and Backplane Hardware
100Ω Differential DS-1
To/From DSx
100Ω Differential DS-1
To/From DSx
To/From
Customer DSX
100Ω Differential DS-1
To/From DSx
100Ω Differential DS-1
To/From DSx
