Appendix A
Hardware Specifications
•
•
•
A.6.18 MRC-2.5G-4 Card Specifications
The MRC-2.5G-4 card has the following specifications:
•
78-18106-01
–
Maximum receiver level: Depends on SFP (see
page
A-5)
–
Minimum receiver level: Depends on SFP (see
page
A-5)
–
Receiver: PIN PD
–
Receiver input wavelength range: Depends on SFP
Environmental
Operating temperature: –40 to +149 degrees Fahrenheit (–40 to +65 degrees Celsius)
–
Operating humidity: 5 to 95 percent, noncondensing
–
Power consumption: 38.00 W, 0.79 A at –48 V, 129.66 BTU/hr
–
Dimensions
Height: 12.650 in. (321.3 mm)
–
Width: 0.716 in. (18.2 mm)
–
Depth: 9.000 in. (228.6 mm)
–
–
Depth with backplane connector: 9.250 in. (235 mm)
–
Weight not including clam shell: 3.1 lb (1.3 kg)
Wavelength plan. Currently available wavelengths and versions of the 15454_MRC-12 card:
–
For ONS-SC-2G-28.7 through ONS-SC-2G-60.0 SFPs: 1527.77 nm to 1560.61 nm
(32 distinct wavelengths at 100 GHz spacing)
Note
ONS-SC-2G-28.7, ONS-SC-2G-33.4, ONS-SC-2G-41.3, ONS-SC-2G-49.3, and
ONS-SC-2G-57.3 are supported from Release 8.5 and later.
–
For ONS-SE-622-1470 through ONS-SE-622-1610 SFPs: 1470 to 1610 nm
(eight distinct wavelengths at 2500 GHz spacing)
–
For ONS_SE-155-1470 through ONS-SE-155-1610 SFPs: 1470 to 1610 nm
(eight distinct wavelengths at 2500 GHz spacing)
Line
Bit rate: up to OC-48 (2488.320 Mbps), depending on SFP
–
Note
Each optical interface on the card can be configured as OC-3, OC-12, or OC-48, depending
on the available backplane bandwidth and existing provisioned lines. In general, the card
supports all different rates on the line side as long as the accumulated bandwidth does not
exceed the total backplane allowed bandwidth.
–
Fiber: 1550-nm single-mode
Connectors: LC duplex connector for each SFP
–
A.6.18 MRC-2.5G-4 Card Specifications
A.2 SFP, XFP, and GBIC Specifications,
A.2 SFP, XFP, and GBIC Specifications,
Cisco ONS 15454 Reference Manual, R8.5
A-45
